AT-TN7100 SERIES
Multiservice Access Platform
MULTISERVICE ACCESS PLATFORM
AT-TN7101
Multiservice access plaform with 48 ADSL ports
(without POTS splitters)
AT-TN7102
Multiservice access plaform with 24 ADSL ports
(with POTS splitters)
THE AT-TN7100:THE TRIPLE PLAY
SOLUTION
The AT-TN7100 delivers high-quality voice, tiered
IP/Ethernet data services, and broadcast-quality
video over existing copper lines. As the newest
member of Allied Telesyn’s TN7000 series of
Multiservice Access Platforms, the AT-TN7100—
together with Triple Play—helps carriers grow rev-
enue and enhance subscriber loyalty.
The Allied Telesyn TN7100 features three card
slots and an environmentally hardened structure
designed for installation in remote enclosures
where reliability is critical.
DELIVERING QOS AND SECURITY
The Allied Telesyn TN7100 employs industry stan-
dard ADSL/ ADSL2+.The AT-TN7100 makes effi-
cient use of network bandwidth by employing
IGMP Snooping to limit broadcast video-streaming
to those channels being watched.The platform also
prevents channel theft with advanced subscriber
filtering capabilities.
Quality of Service implemented with 802.1p prior-
ity bits four classes of service, and Layer 3+ classifi-
cation work together to eliminate jitter and net-
work delay, and to ensure that video and voice
receive network priority.
EASY TO MANAGE
The AT-TN7100 is available in two configurations:
24 ports with integral POTS splitters and 48 ports
without POTS splitters. Also, subtending capabilities
built into the AT-TN7100 make it easy to add
capacity.
The AT-TN7100 and all the members of Allied
Telesyn’s TN7000 series can be managed remotely
and provisioned through the Allied Telesyn
Network Management System (NMS), eliminating
the need for on-site service. Additionally, all net-
work and local management interfaces are located
on the front panel for easy maintenance access.
KEY FEATURES
Designed for Triple Play services:
• Based on IP/Ethernet
• Industry-standard ADSL, upgradeable to ADSL2+
• Rapid Spanning Tree
• IGMP for multicast video
• Quality of Service support
• Subscriber filtering and security
Carrier class:
• Environmentally hardened
• Compact, one RU tall design
• Up to 48 ports
• Integral POTS splitters available
• Centrally managed
