Cycle Count
To display the current cycle count, press the Start
key while the display is showing the temperature in
the sump. The display will show a 2-digit number
indicating how many cycles have been run to
completion (cycles which were stopped in progress
are not counted). Press the Start key to return to
PROGRAM mode without resetting the count.
Press the Up or Down key to reset the count to zero
and return to PROGRAM mode.
Cycle Programming
To edit an existing cycle or create a new cycle, press
the Up key while the display is showing the
temperature in the sump. The display will show
“CY01.” Press the Up or Down key until the
desired cycle number is displayed. Press the Start
key to begin editing the selected cycle.
All cycle programs (“CY01” – “CY30”) can be
customized within a preset program structure. Each
cycle program consists of eight program segments.
See the table below.
When modifying a cycle, a time must be entered for
each segment. To skip a segment or spin, set the
time to “00” and press the Start key. The following
table gives the time parameters for each segment
and spin, as well as the allowable temperature
range.
Note: Spin times in cycle segments 1 – 8 are
entered in seconds (30 to 120), and time for final
spin in segment 11 is entered in minutes (1 to 10).
1. Press the Up key until the computer display
shows the segment to be edited. Press the Start
key.
2. Use the Up or Down key to select the desired
segment time. Set this value to zero to skip the
segment. Press the Start key.
Note: The computer does not count down the
remaining cycle time during fills, drains, or prior to
first achieving the programmed heat temperature
when heating. The computer resumes counting
down cycle time once the programmed fill level is
reached, when the machine has drained, and after a
programmed heat temperature is reached.
Cycle Program Segments
Segment Display Segment Display
Prewash PrE Fill 3 FIL3
Wash UASH Fill 4 FIL4
Fill 1 FIL1 Fill 5 FIL5
Fill 2 FIL2 Fill 6 FIL6
Time And Temperature Parameters
Function Minimum Maximum
Prewash 2 minutes 30 minutes
Wash 2 minutes 20 minutes
Fill 1 2 minutes 15 minutes
Fill 2 2 minutes 15 minutes
Fill 3 2 minutes 15 minutes
Fill 4 2 minutes 15 minutes
Fill 5 2 minutes 15 minutes
Fill 6 2 minutes 15 minutes
Intermediate Spin 30 seconds 120 seconds
Final Spin 1 minute 10 minutes
Temperature 75°F (25°C) 200°F (93°C)
