Page 10 of 16 2342-242/2444A3, 2342-442, 2342-542 Rev: 1/21/2014 7:24 AM
Flash Pattern Configuration
Red every tap 1 Scene
Green every tap 2 Scene Non-Toggle (Always On)
Alternating Green / Red 2 Scene Toggle
Turn LED Off (or Back On)
1) Press & Hold Set Button for 3 seconds - until you hear a beep
Mini Remote’s LED will blink green
2) Press & Hold Set Button a 2
nd
time for 3 seconds - until you hear a beep
Mini Remote’s LED will blink red
3) Press & Hold Set Button a 3
rd
time for 3 seconds - until you hear a beep
Mini Remote’s LED will blink green
4) Press the appropriate area of the paddle for the desired button/scene configuration
Desired LED Mode Button to Press
LED Off Bottom
LED On (default) Top
Mini Remote will double-beep and its LED will turn off
Turn Beeper On During Usage (or Back Off)
1) Press & Hold Set Button for 3 seconds - until you hear a beep
Mini Remote’s LED will blink green
2) Press & Hold Set Button a 2
nd
time for 3 seconds - until you hear a beep
Mini Remote’s LED will blink red
3) Press & Hold Set Button a 3
rd
time for 3 seconds - until you hear a beep
Mini Remote’s LED will blink green
4) Tap Set Button
Mini Remote’s LED will double-blink green
5) Press the appropriate area of the paddle for the desired button/scene configuration
Mini Remote will double-beep and its LED will turn off
Desired Beeper Mode Area to Press
Off (Default) Bottom
On Top
