17
Section 4 Operation
4.1 Using an sc Controller
Before using the sensor in combination with an sc controller make yourself familiar with
the operating mode of the controller. Refer to the controller user manual and learn how to
use and navigate the menu functions.
4.2 Sensor Setup
When a sensor is initially installed, the serial number of the sensor will be displayed as the
sensor name. To change the sensor name refer to the following instructions:
1. Select the Main Menu.
2. From the Main Menu, select SENSOR SETUP and confirm.
3. Select the appropriate sensor if more than one sensor is attached and confirm.
4. Select CONFIGURE and confirm.
5. Select EDIT NAME and edit the name. Confirm or cancel to return to the Sensor
Setup menu.
4.3 Sensor Data Logging
The sc controller provides one data log and one event log for each sensor. The data log
stores the measurement data at selected intervals. The event log stores a variety of events
that occur on the devices such as configuration changes, alarms, warning conditions, etc.
The data log and the event log can be read out in a CSV format. For downloading the logs
please refer to the controller user manual.
4.4 SENSOR STATUS Menu
SELECT SENSOR
ERROR LIST See 6.1 "Error Codes" on page 25 .
WARNING LIST See 6.2 "Warnings" on page 25 .
4.5 SENSOR SETUP Menu
SELECT SENSOR (if more than one sensor is attached)
CALIBRATE
ZERO
Perform a zero cal to remove sensor offset ( 4.6.1 "Zero Cal"
on page 19 ).
1 POINT SAMPLE
Perform a single point calibration ( 4.6.2 "One Point Sample
Calibration" on page 20 ).
TEMP ADJUST
Displays the measured temperature and allows the user to
edit the displayed temperature by ± 5 °C.
DEFAULT SETUP Return the instrument to the default calibration settings.
