English 77
English
Technical data
Subject to changes.
General information
Safety notes
Please read the entire manual before the equipment is unpacked, set up
or put into operation. Observe all hazard and warning notes. Failure to
do so could lead to serious injury of the operator or to damage to the
device.
To make sure that the device safety features are not impaired, this
device must not be used or installed in any manner other than that
specified in this user manual.
Hazard notes in this manual
Note: Information that supplements aspects from the main text.
Performance specifications
Cell
Dual Path Length Pour-Thru Cell,
1 inch/1 cm, plastic
Pour-Thru Cell, 1 cm, quartz glass
Wavelength
range
Plastic 340–900 nm
Quartz glass 190–900 nm
Rinsing volume Minimum of 25 mL
Flow speed 1 mL/second
Interface USB type A
Power supply Via USB cable, 530 mA, 5 V
Ambient storage requirements
–10–60 °C (14–140 °F), 85 % relative
humidity
(without condensate formation)
Ambient operating
requirements 10–40 °C (50–104 °F), 80 % relative humidity
(without condensate formation)
Dimensions 120 Ч 85 Ч 200 mm
Weight 0.5 kg
Enclosure rating IP30
D A N G E R
Indicates a potentially or imminently dangerous situation that, if it is not avoided,
leads to death or to serious injuries.
WA R N I N G
Indicates a potentially or imminently dangerous situation that, if it is not avoided,
can lead to death or to serious injuries.
C A U T I O N
Indicates a possible dangerous situation that can have minor or moderate injuries
as a result.
N O T I C E
Indicates a situation that, if not avoided, could result in damage to the device.
Information that particularly should be emphasized.
