Gearhead dimensions – CGI RTX SERIES: RAPTOR User Manual
Page 2
023RTX 060RTX
034RTX
090RTX
Dimension
Code
Inch (mm)
Metric (in)
Inch (mm)
Metric (in)
Ratio
023RTX
060RTX
034RTX
090RTX
Moment of Inertia Table
(2)
(oz-in-sec
2
)
Gearhead Dimensions
800.568.GEAR (4327) • www.cgimotion.com
pg 7
Pilot Diameter
(+.000/-.002 in)
A
1.500
(38)
50
(1.969)
2.875
(73)
80
(3.150)
Square Flange
B
2.25
(57)
60
(2.36)
3.450
(87)
90
(3.540)
Shaft Length
C
1.25
(32)
30 (1.18)
1.500
(38)
40
(1.57)
Shaft Diameter
(+.0000/-.0005 in)
D
0.500
(12.7)
16
(0.6299)
0.750
(19)
22 (0.8661)
Pilot Length
E
0.062
(2)
3 (0.118)
0.062
(2)
3
(0.118)
Flange Thickness
F
0.250
(6.4)
6.4 (0.250)
0.375 (9.5)
9.5 (0.375)
Key Length
G
0.75
(19)
20 (0.790)
0.980
(25)
25 (0.980)
Key Height
H
0.047
(1.2)
2 (0.079)
0.081 (2.06)
2.5 (0.098)
Key Width
(3)
M
0.125
(3.18)
5
(0.1969)
0.188
(5)
6
(0.2362)
Housing Diameter
I
2.95
(75)
80
(3.15)
4.58
(116)
116
(4.58)
Bolt Hole Diameter
J
0.205
(5.2)
5.6 (0.220)
0.220
(5.6)
6.6 (0.260)
Bolt Circle Diameter
K
2.625
(67)
70 (2.756)
3.875
(98)
100 (3.937)
Gearhead Length
(1)
L1
3.39
(86)
86
(3.39)
4.82
(122)
122 (4.82)
L2
4.28
(109)
108
(4.28)
6.23
(158)
158
(6.23)
L3
5.17
(131)
131
(5.17)
7.63
(193)
194
(7.63)
(1) Gearhead Length based on NEMA motor
mounting.
(2) Gearhead inertia values shown include pinion,
clamp and sleeve, and are for standard NEMA
mounting.
(3) Key Width tolerance for English keys is:
+.001 / -.000 in.
Key Width tolerance for Metric keys is:
+.000 / -.0012 in.
• All specifications are subject to change without
prior notice.
4:1
1.861E-03
1.868E-03
1.295E-02
1.297E-02
5:1
1.676E-03
1.680E-03
1.119E-02
1.121E-02
7:1
1.536E-03
1.538E-03
9.808E-03
9.816E-03
10:1
1.464E-03
1.465E-03
9.111E-03
9.115E-03
16:1
1.702E-03
1.702E-03
1.200E-02
1.200E-02
20:1
1.574E-03
1.575E-03
1.059E-02
1.059E-02
25:1
1.567E-03
1.567E-03
1.051E-02
1.052E-02
28:1
1.484E-03
1.485E-03
9.498E-03
9.498E-03
35:1
1.481E-03
1.481E-03
9.462E-03
9.462E-03
40:1
1.439E-03
1.439E-03
8.944E-03
8.944E-03
50:1
1.437E-03
1.437E-03
8.926E-03
8.926E-03
70:1
1.436E-03
1.436E-03
8.912E-03
8.912E-03
100:1
1.435E-03
1.435E-03
8.920E-03
8.920E-03
160:1
1.437E-03
1.437E-03
8.934E-03
8.934E-03
280:1
1.435E-03
1.435E-03
8.909E-03
8.909E-03
400:1
1.435E-03
1.435E-03
8.919E-03
8.919E-03
500:1
1.435E-03
1.435E-03
8.919E-03
8.919E-03
700:1
1.435E-03
1.435E-03
8.918E-03
8.918E-03
