CGI VP SERIES: VICTORY User Manual
Performance specifications, Design features, Value planetary gearhead
Performance Specifications
1. All torque ratings are based upon 3,000 RPM nominal input speed, and 10,000 hours minimum service life.
2. E-STOP torque rating is limited to 1,000 occurrences.
3. Efficiency rated at 3,000 RPM input speed, at Nominal Rated Torque.
Design Features
• Economical true planetary design
• High torque gear geometry
• Advanced materials and heat treatments
• Compact and efficient design
• 2-year warranty
• NEMA standard frame sizes
• Quick installation
• High reliability design
017VPX
023VPX
034VPX
Value Planetary Gearhead
1 STAGE
2 STAGE
New Product Guide • Fall 2008
Gearbox Weight
1 stage 0.8 lbs / 2 stage 1.1 lbs
1 stage 1.7 lbs / 2 stage 2.2 lbs
1 stage 5.0 lbs / 2 stage 6.0 lbs
Input Speed
5000 RPM Maximum
Backlash (arc-min)
12 (1 stage), 16 (2 stage)
IP Rating
IP54
Service Life
>10,000 HOURS
Efficiency
(3)
1 stage >90% / 2 stage >85%
Operating Temperature
-40°F to +250°F
Shaft Loads
See Tables on Page 12
4:1
109 (12)
137 (16)
221 (25)
201 (23)
253 (29)
409 (46)
744 (84)
937 (106)
1515 (171)
5:1
103 (12)
130 (15)
210 (24)
195 (22)
248 (28)
400 (45)
702 (80)
884 (100)
1429 (161)
7:1
90
(10)
113 (13)
183 (21)
160 (18)
201 (23)
325 (37)
621 (70)
782
(88)
1264 (143)
10:1
81
(9)
102 (12)
153 (17)
140 (16)
177 (20)
285(32)
530 (60)
668
(76)
1080 (122)
15:1
110 (12)
138 (16)
224 (25)
210 (24)
265 (30)
428 (48)
756 (85)
952 (108)
1539 (174)
20:1
120 (14)
151 (17)
244 (28)
221 (25)
279 (32)
451 (51)
830 (94)
1046 (118)
1690(191)
25:1
113 (13)
142 (16)
230 (26)
216 (24)
272 (31)
440 (50)
778 (88)
980 (111)
1585 (179)
28:1
121 (14)
153 (17)
248 (28)
225 (26)
284 (32)
459 (52)
845 (96)
1065 (120)
1721 (194)
40:1
124 (14)
156 (18)
252 (29)
229 (26)
289 (33)
467 (53)
861 (97)
1085 (123)
1754 (198)
50:1
117 (13)
147 (17)
237 (27)
223 (26)
281 (32)
454 (51)
806 (91)
1016 (115)
1642 (186)
70:1
101 (11)
127 (14)
205 (23)
179 (20)
226 (26)
366 (41)
706 (80)
889 (100)
1437(162)
100:1
81
(9)
102 (12)
153 (17)
140 (16)
177 (20)
285 (32)
598 (68)
753
(85)
1217(138)
T
NOM
(1)
T
MAX ACCEL
T
E-STOP
(2)
T
NOM
(1)
T
MAX ACCEL
T
E-STOP
(2)
T
NOM
(1)
T
MAX ACCEL
T
E-STOP
(2)
Ratio
In-lbs
(Nm)
In-lbs
(Nm)
In-lbs
(Nm)
In-lbs
(Nm)
In-lbs
(Nm)
In-lbs
(Nm)
In-lbs
(Nm)
In-lbs
(Nm)
In-lbs
(Nm)
