ENGLISH
4.1 Gearmotor
The BK-BKE gearmotor is designed and built by CAME CANCELLI AUTOMATICI S.p.A. and it meets the safety standards in force.
Guaranteed 24 months if not tampered with.
The case consists partly of cast aluminium, inside of which operates the non-reversible electromechanical gearmotor, and partly
of a covering in ABS plastic inside of which is an electronic card and the transformer.
There are 4 versions of this unit:
BK800 – automated unit with M4 pinion module, max capacity 800 kg;
BK-BKE 1200/1210 – Automated unit with M4 pinion module, max capacity 1200 kg;
BK-BKE 1800/1810 – Automated unit with M4 pinion module, max capacity 1800 kg;
BK-BKE 2200/2210 – Automated unit with M6 pinion module, max capacity 2200 kg;
The BK-BKE gearmotor may be supplied with complementary accessories such as:
001 R001 - Lock cylinder with DIN keys;
001 BSF - Braking device for gates installed on a sloping surface;
001 BRC5/10/15 - Power supply cable winding device for sensitive safety profi les;
001 B4353 - Chain transmission device;
009 CGZ - Galvanized steel 22 x 22 module 4 rack;
009 CGZS - Galvanized steel 30 x 8 module 4 rack with fastening screws, holes and supports;
009 CGZ6 - 30 x 30 module M6 galvanised rack made of laminated steel for BK2200 and BKE2200 automated units;
009 CCT - Simple 1/2” chain;
009 CGIU - 1/2” chain joint.
Important! Check that the safety equipment and accessories are CAME originals; this is a guarantee that also makes the system
easy to set up and upkeep.
4 Description
2.1 Destination
1 Legend
This symbol indicates sections to be read with particular care.
This symbol indicates sections concernig safety
This symbol indicates notes to communicate to users.
The following standard were complied with for this product: EN 12978, UNI EN 954-1, CEI EN 60335-1, UNI EN 12453.
2 Destination and limits of use
The BK-BKE gearmotor is designed to automate sliding gates for residential and condominium complexes.
The use of this product for purposes other than the one intended and installation carried out in a manner other than as
instructed in this technical manual are prohibited.
3 Standard followed
“IMPORTANT SAFETY INSTRUCTIONS FOR INSTALLATION”
“CAUTION: IMPROPER INSTALLATION MAY CAUSE SERIOUS DAMAGE, FOLLOW ALL INSTALLATION INSTRUCTIONS CAREFULLY”
“THIS MANUAL IS ONLY FOR PROFESSIONAL INSTALLERS OR QUALIFIED PERSONS”
2.2 Limits of use
Maximum gate weight 2200 kg with maximum length of 13 meters.
4.2 Technical information
*Obtained with CAME control panel.
GEARMOTOR WEIGHT POWER
SUPPLY
CURRENT POWER DUTY CICLE MAX
TORQUE
REDUCTION
RATIO
PUSH MAX
SPEED
CONDEN-
SER
PROTECTION
LEVEL
OPERATING
TEMPERATURE
BK-800 21 Kg. 230 V a.c. 4,5 A 520 W intensive service * 28 Nm
1/31
800 N
10,5
m/min
22 µF
IP54
-20° C
+55° C
BK-BKE 1200
18 Kg.
230 V a.c. 3,3 A 380 W
50%
* 31 Nm 850 N
25 µF
BK-BKE 1210 120 V a.c. 5,6 A 310 W 100 µF
BK-BKE 1800
19,5 Kg.
230 V a.c. 4,2 A 480 W * 42 Nm 1150 N 31,5 µF
BK-BKE 1810 120 V a.c. 8 A 440 W * 40 Nm 1100 N 140 µF
BK-BKE 2200
21 Kg.
230 V a.c. 5,1 A 580 W * 54 Nm 1500 N 35 µF
BK-BKE 2210 120 V a.c. 9,1 A 500 W * 51 Nm 1400 N 160 µF
