How Your 5600 SE Water Filter Works
Raw water enters your home through the main supply line, enters your filter, and passes downward through the media
bed. Impurities such as turbidity and sediment (multi-media filter) and organics and chlorine (taste and odor filter) are
removed from the water. The filtered water then flows into your household water lines.
Periodic regeneration is required to flush entrapped material from the system.
In normal operation, the Time of Day display will alternate being viewed with the Volume Remaining display. This display
will be in gallons. As treated water is used, the Volume Remaining display will count down from a maximum value to zero
or (---). Once this occurs, a regeneration cycle will be initiated at the Set Regeneration Time. Water flow through the valve
is indicated by the Flow Dot that will flash in direct relationship to flow rate.
Example 833 Gallons of Treated
Water Remaining
0 Gallons of Treated
Water Remaining
In regeneration, the control will display a special regeneration display. In this display, the control will show the current
regeneration step number the valve is advancing to or has reached and the time remaining in that step. The step
number displayed will flash until the valve has completed driving into this regeneration step position. Once all
regeneration steps have been completed, the valve will return to Service and resume normal operation.
Example Less than 6 minutes
remaining in Regen
Step #1
Pushing the extra cycle button during a regeneration cycle will immediately advance the valve to the next cycle step
position and resume normal step timing.
1
833
Flow
Flow
P.M.
P.M.
Service
Service
Program
Program
Program
Service Flow
P.M.
1 - - 5
•
- - -
•
• •
Performance and Specifications
Item Model Pipe Service Peak Backwash Mineral Shipping
Number Number Media Size Flow Rate Flow Rate Flow Rate Tank size Weight
cu. ft. (litres) inches (mm) USGPM (LPM) inches (mm) Lbs. (kg)
7615 5600SEM-847AC 0.75 (21) 3/4 (19) 4.0 (15) 5.0 (19) 3.5 (13) 8 x 47 (203 x 1194) 45 (20)
7616 5600SEM-948AC 1.00 (28) 3/4 (19) 4.0 (15) 6.0 (23) 4.0 (15) 9 x 48 (229 x 1219) 60 (27)
7617 5600SEM-1054AC 1.50 (42) 3/4 (19) 5.0 (19) 7.0 (27) 5.0 (19) 10 x 54 (254 x 1372) 78 (35)
Hydrotech Taste & Odor Filter (Carbon)
Item Model Pipe Service Peak Backwash Mineral Shipping
Number Number Media Size Flow Rate Flow Rate Flow Rate Tank size Weight
cu. ft. (litres) inches (mm) USGPM (LPM) inches (mm) Lbs. (kg)
7618 5600SEM-847MM 0.75 (21) 3/4 (19) 4.0 (15) 5.0 (19) 4.0 (15) 8 x 47 (203 x 1194) 95 (43)
7619 5600SEM-948MM 1.00 (28) 3/4 (19) 5.0 (19) 7.0 (38) 5.0 (19) 9 x 48 (229 x 1219) 145 (66)
7620 5600SEM-1054MM 1.50 (42) 3/4 (19) 7.0 (38) 10.0 (38) 7.0 (38) 10 x 54 (254 x 1372) 213 (97)
Hydrotech Turbidity Filter (Multi-Media)
Notes:
Operating Temperature Range: 34° to 110°F (1° to 43°C)
Operating Pressure Range: 20 to 120psi (137 to 827 kPa)
Electrical: 24V/60Hz with a supplied 120V/60Hz Wall Mount CSA Approved Transformer
1. The manufacturer reserves the right to make product improvements which deviate from the
specifications and descriptions stated herein without obligation to change previously manufactured
products or to note the change.
2. Peak flow rates are intended for intermittent use only and are for residential application only.
Caution: These water conditioners are not intended to be used for treating water that is microbiologically unsafe or of unknown quality without adequate
disinfection before or after the system.
