Model 5600 & 5600 Econominder
®
15
Model 5600 Control Valve Drive Assembly
▲
Not used when a filter valve
Item Number
No. Req’d
Part Number
Description
1
1
14448-010
housing, with pin
1
14448-011
housing, with pin drilled for screw
1
14448-012
housing, with pin drilled for thumb screw
1A
1
15494-01
“L” housing, with pin
1
15494-03
“L” housing, with pin drilled for designer
2
1
13175
motor mounting plate
3
1
18743
motor, 120V, 60 Hz
1
19659
motor, 24V, 60 Hz
4
(2-3)
11384
screw, motor mtg. and ground wire
5
(3-5)
13296
screw, component mounting
6
1
13017
idler gear
7
1
13018
idler pinion
8
1
13312
spring, idler
9
1
13164
drive gear
11
1
13170
main gear and shaft
12
1
19205
24-hour gear assembly, silver
1
19205-01
24-hour gear assembly, tan
13
1
13011
cycle actuator gear
14
1
14177
knob, manual regeneration
15
4
13300
ball, 1/4
″ dia.
16
2
13311
spring, detent, skipper wheel
19
1
14381
skipper wheel assembly, 12-day
1
14860
skipper wheel assembly, 7-day
20
1
13864
skipper wheel ring
21
2
14457
spring, detent, main gear
22
1
13014
regeneration pointer
23
1
11842
electrical cord, standard
24
2
12681
wire connector (not shown)
25
1
13547
strain relief
26
1
13229
back cover
27
1
13309
front label, brown on beige
1
13437
front label, blue/silver on black
28
1
13310
rear label, softener
1
18520
rear label, filter
29
1
13348
tape stripe, brown on beige
1
13436
tape stripe, blue on silver
30
▲
1
60514
brine cam assembly, 3-18
1
60514-01
brine cam assembly, 6-36
1
60514-02
brine cam assembly, minutes
34
2
12473
screw-drive mounting
35
▲
1
12037
washer
37
1
15151
screw, knob
38
1
14176
valve position dial, standard
1
14278
valve position dial, low water
1
15478
valve position dial, chemical filter
1
16715
valve position dial, filter
39
1
14175
knob label, beige
1
14207
knob label, silver
40
▲
1
40214
screw, brine cam
