1.
EJECT(
) Button - Press this button to eject discs from the disc
compartment.
(
) Button - Press this button to select
or
aspect ratios.
Button -
,
h
,
,
Ch3
88.5 Mhz,
,
,
,
,
,
,
,
,
,
,
,
,
.
SCREEN RELEASE (PRESS) Button - Press this button to release the
LCD screen. The screen will drop down slightly. Pivot the screen
downward until a comfortable viewing angle is reached
Button - Press
d
Press to adjust
in the following sequence: Brightness, Contrast, Hue, Saturation, Reset.
6
SOURCE Button - Press to select the source menu: DVD/AV1/SD/USB.
7.
POWER( ) Button - Press this button to turn the system on or off.
8.
STOP(
) Button - Press this button to stop playback.
9.
PLAY/PAUSE( ) Button - Press to start playback or pause playing.
10. VOLUME ( ) Button - Press this button to decrease the volume or
decrease the level of selected picture controls.
11. VOLUME (
) Button - Press this button to increase the volume or
increase the level of selected picture controls.
12. DOME LIGHTS - Provides additional interior illumination.
13. Ventilation openings
14. LCD Cut Off Switch - Used to turn off the LCD screen when in the closed
position.
15. 9” LCD screen
16. Wireless Headphone Transmitter - Transmits audio to an optional
wireless headphone.
17. Infrared Remote Sensor - Allows remote control to operate the unit.
2.
SCREEN MODE
Wide (16:9)
Normal (4:3)
3.
FMM
Used to select the frequency in sequence rotation: FM OFF
C 1
88.1 Mhz
Ch2
88.3 Mhz
Ch4
88.7 Mhz
Ch5
88.9 Mhz
Ch6
89.1 Mhz
Ch7
89.3 Mhz
Ch8
89.5 Mhz
Ch9
89.7 Mhz
Ch10
89.9MHz
Ch11 90.1 Mhz
Ch12 90.3 Mhz
Ch13
90.5 Mhz
Ch14 90.7 Mhz
Ch15 90.9 Mhz
Ch16
91.1 Mhz
4.
.
5.
PIC
to enter the picture a justment mode.
-
+
CONTROLS AND INDICATORS DIAGRAM
4
Front View
