Installation Manual
© Hydra-Flex Inc 2011 - 5 -
Estimated Timeline
Pre-Installation
Who Task Est. Time
Distributor & Customer Determine location to install equipment 1 hr
Plumber Install water supply line 4 hrs
Electrician Install electrical supply line 4 hrs
Technician Label all controller relays at MCC or junction box 1 hrs
Technician Run solution and air lines 5 hrs
Technician Install air supply line 1 hr
Total Labor Hours 16 hrs
Installation
Who Task Est. Time
Technician Hang equipment 1 hr
Technician Connect water, air and solution lines 1 hr
Technician Connect control leads to main controller or junction box 2 hr
Distributor / Technician Startup (injector, metering tip and nozzle selection) 3 hr
Distributor / Technician Document configuration 1 hr
Total Labor Hours 8 hrs
Post Installation
Who Task Est. Time
Distributor Monitor & record performance 2 hrs / wk
Distributor Maintenance per schedule or as needed
Total Customer 1 hr
Total Distributor/Technician 15 hrs
Total Electrician 4 hrs
Total Plumber 4 hrs
Installation takes approximately two days for a two technician team. An electrician and a plumber are needed for
half a day on the first day.
