Installation Manual
© Hydra-Flex Inc 2011
- 4 -
Feed Water Connection (if using HFI pump)
**PRIOR TO CONNECTION, ENSURE THAT THE FEED LINES ARE FREE OF DEBRIS BY FLUSHING OUT THE
LINES FOR 15 MINUTES
• Connect pre-run main water supply line to pump inlet.
Feed Water Connection (if using existing pump)
**PRIOR TO CONNECTION, ENSURE THAT THE FEED LINES ARE FREE OF DEBRIS BY FLUSHING OUT THE
LINES FOR 15 MINUTES
• Connect supply from regulated pump.
Pneumatic Connections
**IF USING AIR PILOT VALVES. IF NOT SKIP THIS SECTION
• Connect pre-run 1/4" OD poly feed line to push connect fitting on
the side of the valve bank
