Installation Manual
© Hydra-Flex Inc 2011 - 2 -
Installation Instructions
General Skill Level
• Mechanical: Basic - mounting equipment
• Electrical: Advanced - three phase power and controls knowledge
(local codes knowledge required)
• Plumbing: Moderate – principal supply line required
• Pneumatic (if needed): Basic- pneumatic utility connection required
• Chemical Knowledge: Moderate : Advanced - chemical titrations required
Tools and Equipment Needed
• Drill with Phillips head
• Concrete drill bit 3/8”
• Hammer
• Tape measure
• Level
• Utility knife
• Wire stripper
• Socket set
• Adjustable wrench
• Screw driver set
• Teflon tape
Aqua-Lab SD Air Operated Valve with Pilots
Air Pilot Valve
Valve
Hydra-Cannon Manifold
1 2 3 4 5 6 Water Ports
