System Component Identification
Air Regulator 1, 2, 3
Air Solenoid
Valve
Board Mounting Slots
Air Inlet
(3/8” Poly)
Pneumatically
Actuated Valve
Water Feed
From Pump
(200psi)
Triple Foam
Manifold
Chemical
Injector
3x Outlet to Applicator
Air Outlet 1,
2, 3
