AMERICAN SANDERS TECHNOLOGY -American 12 Floor Sander Operator's Manual
Page 25
Ref. No Part No.
Description
Qty Qty
1
88502A
Screw, 10-24 x
3
/
8
Set
2
2
2
25200C
Knob, Hand
1
1
3
67309A
Screw, Sustainer
1
1
4
87000A
Washer
1
1
5
67907A
Spring, Sustainer
1
1
6
67315A
Screw
3
3
7
66123A
Plunger, Spring
3
3
8
67109A
Rod, Pilot
1
1
9
920196
Nut, ½-13 Hex Jam
3
3
10
87101A
Washer, ½ Lock
3
3
11
67906A
Spring
3
3
12
Ref.
Frame, Main
1
1
13
57100A
Button, Plug
1
1
14
66628C
Plate, Cover Wheel
2
2
15
962015
Screw, 10-24 x
3
/
8
Pn St Mach
6
8
16
980650
Washer,
3
/
16
Lock
6
6
17
23801A
Guard, Belt
1
1
18
60715B
Bolt, Pivot
1
1
19
962823
Screw, ¼-20 x ½ Pn St Mach
3
3
20
980657
Washer, ½ Lock
3
8
21
67814A
Spacer
1
1
22
86202A
Screw,
5
/
8
-11 x
5
/
8
St
2
2
23
67909A
Spring
2
2
24
51113A
Ball, ½ Diameter
2
2
25
21902C
Clamp
2
2
26
962892
Screw, ¼-20 x
5
/
8
Pn St Mach
4
4
27
68001A
Stud, Belt Guard
1
1
28
62801A
Shaft, Cont. Ecc.
1
1
29
980614
Washer, #1114 Shakeproof
1
1
30
87007A
Washer, Cont. Shaft Ecc.
13
13
31
85806A
Screw, ¼-20 x 1 Hex St
1
1
32
81209A
Nut, Large Flange ½-13
1
1
33
u
60547A
Axle
-
2
34
66913A
Retainer, Bearing
1
1
35
51112A
Bearing
2
2
36
67821A
Spacer
1
1
37
u
51225A
Bearing, Ball
6
6
38
29403C
Yoke, Wheel
1
-
39
60101A
Axle
3
1
40
920160
Nut,
5
/
16
-18 Hex JAM
1
1
41
87006A
Washer,
9
/
16
x 1
3
/
8
x 10
ref. ref.
42
26000C
Nut, Retaining
1
1
43
86201A
Screw,
5
/
16
-18 Set
1
1
44
67144A
Rod, Control
1
1
45
62000A
Nut, End
1
1
46
26502A
Plate, Plunger
1
1
47
85811A
Screw,
5
/
16
-18 x
3
/
4
Hex St Cap
4
4
48
920260
Nut,
3
/
8
-16
Hex
1
1
49
53917B
Fork, Control
1
1
50
66503A
Pin, Fork
1
1
51
925036
Pin,
3
/
32
x
3
/
4
Cotter
1
1
52
25600A
Lever, Reach
1
1
53
67416A
Shaft, Lever
1
1
54
67810A
Spacer
2
2
55
u
60544A
Spacer
-
2
56
59928A
Wheel (Steel)
3
-
u 10243A
Kit, Wheel (Urethane) (Optional)
-
-
59907A
Wheel (Canvas)
-
1
57
67817A
Spacer
3
3
58
87003A
Washer
2
2
59
54000A
Fitting, Grease
2
2
60
u
167312
Ring, Retainer
2
2
61
u
60481A
Spacer
2
2
62
u
50992A
Wheel, Assemlby
-
2
AMERICAN SANDERS TECHNOLOGY
American 12 Floor Sander
Assembly Parts List #3 6/01
NOTE:
u indicates a change has been
made since the last publication
of this manual.
07048C
07049C07108A 07109A
