AMERICAN SANDERS TECHNOLOGY -American 12 Floor Sander Operator's Manual
Page 23
AMERICAN SANDERS TECHNOLOGY
Model American 12 Floor Sander
Parts List #2 10/00
Ref # Part No. Description Qty Ref # Part No. Description Qty
1 62800A Pipe, Ass'y 1
2 85714A Screw, ½ - 13 x 2¼ Hex 1
3 87006A Washer, .56 X 1.38 X .11 Flat 1
4 962216 Screw 3 /
8
-16 x 1¼ Hex 4
5 962870 Screw 3 /
8
-16 x 1 1
6 44639A Motor 4 hp 230V/60 1
44640A Motor 3 hp 240V/50 1
7 64460A Handle, Motor 1
8 66164A Pulley, Motor 1
9 51028A Belt-V 1
10 60401A Arm, Cable 1
11 925044 Pin, 3/32 x 1 Cotter 1
12 66110A Pipe Assembly 1
13 50954A Dust Bag 1
14 84220A Screw, ½-13 x 2¼ Ft. 1
15 68704A Washer - Motor Screw 1
16 26108C Platform, Motor 1
17 51021A Belt - V 1
18 68002A Stud 1
19 26102A Pan, Dust 1
20 920256 Nut, 5 /
16
-18 Hex 2
21 85820A Screw, 3 /
8
-16 x 5 /
8
Hex 3
22 85816A Screw, 5 /
16
-18 x 1 3 /
4
Hex 1
23 27801C Support, Dust Pipe 1
24 67820A Spacer, Motor Screw 1
25 87101A Washer, ½ Lock 1
26 920196 Nut, ½-13 Hex Jam 1
27 30501A Bushing 1
28 85817A Screw, 5 /
16
-18 x 2" Hex 1
29 34224A Gasket 1
30 81202A Nut, 7 /
16
-14 Hex L.H. 2
31 87002A Washer 2
32 23300A Fan 1
33 39704A Washer, Felt 1
34 24504C Housing, Fan 1
36 902567 Bearing 1
37 34223A Gasket, Support Pipe 1
38 23406C Frame 1
39 962983 Screw, ¼-20 x 5 /
8
Pan 6
NI 18601A Shaft Ass'y Drum (1)
includes D56, D39. D71
40 980657 Washer, ¼ Lock 9
41 62608C Cover, Drum Housing 1
42 67314A Screw, Special 1
43 70042A Label, I.D. American 12 1
44 51110A Bearing 2
45 64703A Housing, Bearing 1
46 67818A Spacer, Drum Shaft 1
47 915028 Key - #5 Woodruff 2
48 67424A Shaft Fan 1
49 51111A Bearing 2
50 62001A Cap, Bearing 1
*NOTE: #57 Not Illustrated
51 962288 Screw, 3 /
8
-16 x 1" Hex 2
52 67816A Spacer 1
53 20401B Arm 1
54 67815A Spacer, Idler Bearing 1
55 68101A Stud 1
56 67413A Shaft 1
57* 38109A Seal, Dust Pipe 1
58 77234A Label, Lifting Warning 1
59 962823 Screw, ¼-20 x ½ Pan 3
60 66172A Pulley, Fan Shaft 1
61 67417A Shaft, Drum Cover 1
62 13500A Drum Assembly 1
63 67819A Spacer, Drum Shaft 1
64 66918A Retainer, Bearing 1
65
66
67
66165A Pulley, Drum 1
68 980644 Washer, 5 /
8
Plain 1
69 920280 Nut, 5 /
8
-18 Hex Jam 1
70 962262 Screw, 8-32 x ¼ Set 1
71 55400A Key - #9 Woodruff 3
72 67415A Shaft, Drum 1
73 67911A Spring 1
74 22111A Cover, Drum 1
75 31211A Bumper Assembly 1
76 85517A Screw, 10-24 x ½ PN 5
77 86202A Screw, Set 5 /
8
-11 1
78 67908A Spring 1
79 66115A Plunger 1
80 29402A Yoke 1
81 66505A Pin, Yoke 1
82 925036 Pin, 3 /
32
x 3 /
4
Cotter 1
83 877304 Ring Retaining 1
84 920148 Nut, 3 /
8
-16 Hex Jam 1
85 87000A Washer 1
86 61602A Collar 1
87 32357A Cover Handle 1
88 930087 Rivet 2
89 74044A Plate Safety 1
90 62904A Enclosure Motor 1
91 697502 Strain Relief Bushing 1
92 41305A Capacitor, Start 2
93 41304A Capacitor, Run 1
94 47378A Switch, Start 1
95 962823 Screw, ¼-20 X ½ 2
96 980614 Washer 2
97 45604A Plug 1
98 41945A Cord, Motor 1
99 915098 Key, ¼ Sq. x 1¼ 1
100 57712A Ring, Retaining 1
101 87034A Retainer Pulley 1
102 962288 Screw, 3 /
8
-16 x 1 1
103 66173A Pulley Idler 1
Part # Description Qty.
51188A Bearing Front 1
902547 Bearing Rear 1
40316A Armature Assembly 1
Part # Description Qty.
50563A End Bell 1
52768A Front Cover 1
53998A Fan 1
52769A Fan Cover 1
Motor Parts Not Illustrated
