AMERICAN SANDERS TECHNOLOGY -American 12 Floor Sander Operator's Manual
Page 21
Ref No. Part No Description Qty
1 Ref. Cord Assembly 1
2 41706A Connector (NEMA) 1
3 962065 Screw - 8-32 x ¼ Pn St Mach 3
4 43501A Inlet - 20A, 250V 1
5 85313C Screw - 6-32 x ¼ Pn St Mach 4
6 980607 Washer - #1106 Shakeproof 4
7 962794 Screw - 10-24 x 1 Pn St 5
8 980650 Washer - 3 /
16
Lock 5
9 22127C Cover - Switch Box 1
10 48901A Wire Ass'y - Green 1
11 48900A Wire Assembly - Ground 1
12 980699 Washer - #1210 Shakeproof 3
13 49023A Wire Assembly Black 2
15 962015 Screw - 10-24 x 3 /
8
3
16 80022A Bolt ½ x 5 /
8
1
17 67129A Adjuster Control Rod 1
18 41411A Switch - Circuit Breaker 1
19 980603 Washer #8 Shakeproof 1
20 85833A Screw, #10-32 Ground 1
21 920284 Nut ¼-20 2
22 66694A Plate Control Lever 1
23 962481 Screw ¼-20 x 1¼ 2
24 980646 Washer ¼ 1
25 25602A Lever Control 1
26 66151A Pivot Control Rod 1
27 80021A Bolt 3 /
8
x 5 /
8
1
28 85818A Screw 5 /
16
-18 x 2¼ Hex St 1
29 21904C Clamp - Handle 1
30 64405A Handle - Steering 1
31 86200A Screw - 3 /
8
-16 Set St 2
32 920110 Nut 5 /
16
-18 ESNA 2
33 20704C Box - Switch 1
34 85816A Screw 5 /
16
-18 x ¾ Hex St Flt Hd 2
35 66114C Pipe - Handle 1
36 41917A Cord - Interconnecting 1
37 962288 Screw 3 /
8
-16 x 1" Hex St Cap 3
38 21102C Bracket - Handle 1
39 62609A Cover, Handle Bracket 1
40 962016 Screw 10-24 x ½ Pn St Mach 2
41 170637 Connector, Conduit 1
42 980638 Washer - 3 /
8
Diameter Lock 3
43 41707A Connector 1
44 67144A Rod Control 1
45 920148 Nut 3 /
8
-16 Jam 1
46 45608A Plug (NEMA) 1
AMERICAN SANDERS TECHNOLOGY
Model American 12 Floor Sander
Parts List #1 Handle Asembly 10/00
