8 9 10
20.
Bounce the vehicle checking for clearance on all under carriage components: fuel tank, shocks, differential, brake and
fuel lines, etc. Test drive the vehicle and recheck all clearances and the installation alignment. Adjust as needed. Re-check your
installation after one week of driving and periodically on a regular basis.
21.
The sway bars arms have three mounting holes. Mounting the sway bar on the outer hole (forward-most) is the nominal
position. For a firmer setting, use the inner holes. We recommend starting with the outer mounting hole until you are
accustomed to the vehicles new handling characteristics. Select the mounting point that best fits your driving style.
ATTENTION INSTALLER: BE SURE THAT THE CUSTOMER RECEIVES THIS INSTRUCTION
SHEET, ALL IMORTANT NOTE CARDS AND THE WARRANTY FORM
559-734-7451 800-367-5480 FAX 559-734-7460
7869 (R-7869) 07/13/2011
Washer
Sleeve Tube
End Link
