PARTS LIST
RSB KIT # 7649
“00-04” 8.1 SUBURBAN (2&4WHL)
PART # QTY DESCRIPTION
20217649 1 1-1/4” SWAY BAR
20907649 1 COMPLETETION KIT # 7649
118020638 2 1/2” X 5” X 7” ROUND U-BOLT
20800149 2 PLATE BRACKET
20800148 2 U-PLATE
111000649 2 1-1/4” POLY BUSHING
20800059 2 1-3/8” CLEVIS BRACKET
20800044 1 SPACER PLATE
20800061 2 END LINK
125000116 1 SMALL PARTS BAG # BG-116
101500307 2 1/2” X 1-1/4 CAP SCREW
107521044 2 1/2" LOCK NUT
101500185 4 7/16” X 2-1/4’ CAP SCREW
107401042 4 7/16" LOCK NUT
111000050 2 5/8" HOUR GLASS POLY BUSHING
20800046 2 7/16” X 1-3/8” STEEL SLEEVE
105521044 8 1/2" HEX NUT
102520043 8 1/2” FLAT WASHER
102420041 4 7/16” FLAT WASHER
111000389 4 END LINK POLY BUSHING
101500047 1 M12 X 1.5M X 50 MM CAP SCREW
20800428 2 Z- BRACKET
20800723 2 END LINK SPACER ( 1/2”X 1-1/4” )
135000382 1 INSTRUCTION SHEET R-7649 (R-382)
7649 (R-382 ) 12/09/04
559-734-7451 800-367-5480 FAX 559-734-7460
