Hellwig Sway Bar 7555 User Manual
Installation instructions
R-7555
5/30/2008
INSTALLATION INSTRUCTIONS
1988-98 C/K 1500-2500-3500 Single Wheel
Rear Stabilizer Bar
Thank you for purchasing a quality Hellwig Product.
559-734-7451 800-367-5480 FAX 559-734-7460
Align end links for best fit
and drill 17/32 (.531”) hole
in frame to attach end link to
frame with 1/2” bolt.
Install jam nut
and hex nut on
top of bushing
assembly
Install lock nut on
bottom of bushing
assembly.
