1. If equipped, remove the factory installed anti sway bar and the mounting hardware.
2. Locate holes in K-member and install the mounting brackets and crossbars as shown in photo (2).
Attach the mounting brackets with 3/8-16 X 1” bolts, washers, and locknuts. Insert the 3/8-16 X 1-
1/4” bolts into crossbars as shown in photo (2). After inserting crossbars with bolts, tighten frame
bolts to 25 ft-lb.
3. Lubricate and install the D-shaped polyurethane bushings on the new sway bar in locations shown in
photo (1). Attach U-plates to bushings and mount sway bar to brackets using flanged nuts. Leave
loose at this time for adjustment later.
4. If equipped with factory sway bar mounts, assemble end links as shown in diagram below. Tighten
nut until bushings bulge slightly
5. If not equipped with factory sway bar mounts, remove lower shock bolt and attach angle brackets to
lower control arm as shown in photos (4) & (5) using 7/16-20 x 2-3/4” bolt with thick washer placed
between control arm and bracket. Torque bolt to 40-45 ft-lb.
