Hellwig Air 6211 User Manual
Page 3
559-734-7451 800-367-5480 FAX 559-734-7460
4. Install heat shield and frame bracket
as shown. (Passenger side shown.
Drivers side heat shield not required)
Torque nuts to 20 ft-lb.
4
3. Lay out base plate as shown in photo. Attach air spring to base plate using 3/8” x
1” bolt as shown in photo.
Torque to 20-25 ft-lb.
Attach air spring to plate us-
ing the forward hole when
bracket is placed on axle.
(Passenger side shown)
3
6211 ( R-6211)
11/30/06
