Hellwig Helper Spring 979 User Manual
Page 2
IMPORTANT NOTE
05-11 TOYOTA TACOMA
APPLICATIONS
INSTALLATION OF THIS KIT ON 2005-11
TOYOTA TACOMA APPLICATIONS REQUIRES
INSTALLATION OF SHACKLE KIT AS
SHOWN ON DRIVER’S SIDE FRONT SPRING
NEXT TO FUEL TANK.
559-734-7451 800-367-5480 FAX 559-734-7460
Install U-bolt as shown
with legs pointing out-
Compress spring with C-Clamp.
Install crossbar on outboard side of
spring and attach with lock nuts as
shown. Torque locknuts to 20-25 ft-
(979)
12/16/2011
