OPERATOR’S MANUAL
High Amps Probe 927
To Measure Low Amps with a DMM
1.
Connect the High Amps Probe to the interface module.
2. Connect the interface module to the multimeter’s
banana jacks.
3. Select the millivolts range.
4. Close the Jaws on the High Amps Probe and zero the
reading on the DMM by adjusting the zero knob on
the interface module.
5. Clamp the High Amps Probe around the circuit you
want to test. 1 Millivolt equals 1 Amp. A reading on
the Multimeter of 125.1 Millivolts means you are
measuring 125.1 Amps.
To View Waveforms on a Lab Scope
1.
Connect the High Amps Probe to the interface module.
2. Connect the interface module to one of the LabScope’s
Channels. Use the BNC or Banana Adapter as
needed.
3. Select a volts per division and a time base that will
allow you to see the waveform of the circuit under test.
4. Make sure the jaws are closed on the Amps Probe
and zero the trace on the LabScope by adjusting the
zero knob on the interface module.
5. Clamp the High Amps Probe around the circuit you
want to test and view the waveform.
Other Instructions
The interface module has two power options. The first time
you press the power button the LED will flash indicating
the unit will stay on until the battery is dead.
The second time you press the power button, the LED will
stay on indicating the unit will automatically power down in
5 minutes.
The third time you press the power button the unit will turn
off.
Technical Support
For additional information or technical assistance, please
contact Ferret Instruments at (800) 627-5655 or
www.ferretinstruments.com.
FEATURES
High Amps Probe measures
from 1 Amp to 600 Amps AC
or DC.
Connects to any Digital
Multimeter w/Banana Jacks
and a millivolt scale.
Connects to any Graphing
Multimeter or Labscope w/
Banana Jacks or BNC
connectors.
Powered by a 9 Volt battery.
3 Year Limited Warranty
