Idler bearing assembly – American Dryer Corp. WDA-385 User Manual
Page 19
450195-3
17
Illus. No.
Part No.
Qty.
Description
1
100111
1
5L650 “V” Belt (basket / tumbler to idler)
(prior to April 16, 1999)
100189
1
5L540 “V” Belt (basket / tumbler to idler)
(as of April 16, 1999)
2
101129
1
9” x 2-1/2” Compound Pulley ONLY
3
100101
1
4L480 “V” Belt (idler to motor)
4
54301
4
5/16-18 x 1 Cone Point Set Scew
5
100705
1
3/16” x 3/16” x 1-3/8” Key
6
301850
1
5/8” x 3/4” Idler Shaft ONLY
7
150529
3
1/4-20 x 2-1/4” Carriage Bolt
8
100214
2
5/8” Flange Bearing (with flanges) ONLY
9
153007
3
1/4” Lock Washer
10
152002
3
1/4-20 Hex Nut
11
801008
1
Idler Bearing Assembly Complete
(includes illus. nos. 6 through 22)
100406
1
Idler Bearing Mount ONLY
2
150613
1
5/16-18 x 4” Hex Head Machine Bolt
13
150617
2
3/8-16 x 1” Hex Head Machine Bolt
14
153005
2
3/8” Lock Washer
15
153004
2
3/8” Flat Washer
16
152020
1
5/16-18 Standard Square Nut
17
152004
1
5/16-18 Hex Nut
18
152005
1
3/8-16 Hex Nut
19
153005
1
3/8” Lock Washer
20
150617
1
3/8-16 x 1” Hex Head Machine Bolt
21
301851
1
Idler Bracket Adjustment Plate
22
801009
1
Idler Square Washer
Idler Bearing Assembly
