Tumbler bearing assembly – American Dryer Corp. WDA-385 User Manual
Page 17
450195-3
15
Illus. No.
Part No.
Qty.
Description
1
880203
1
1-3/8” Flange Bearing
2
153005
4
3/8” Lock Washer
3
152005
4
3/8-16 Hex Nut
4
150508
2
3/8-16 x 3/4” Hex Head Machine Bolt
5
153005
2
3/8” Lock Washer
6
152005
2
3/8-16 Hex Nut
7
150600
2
3/8-16 x 1/2” Hex Head Machine Bolt
8
153004
2*
3/8” Flat Washer
9
153005
2
3/8” Lock Washer
10
152005
2
3/8-16 Hex Nut
11
150501
4
5/16-18 x 3/4” Hex Head Machine Bolt
12
153002
4
5/16” Lock Washer
13
153001
4
5/16” Flat Washer
14
150621
2
5/16-18 x 1-1/2” Hex Head Machine Bolt
15
152004
2
5/16-18 Hex Nut
16
801101
1
1-3/8” Bearing Box Assembly Complete
(for models mfg. without Rotational Sensor)
(includes illus. nos. 4 through 20)
801103
1
1-3/8” Bearing Box and Support Assembly ONLY
(includes illus. nos. 4, 5, 6, 16, and 17)
801105
1
1-3/8” Bearing Box ONLY
17
801104
1
1-3/8” Pillow Block Bearing Support ONLY
18
880202
1
1-3/8” Pillow Block Bearing ONLY
19
152004
2
5/16-18 x 1-1/2” Allen Set Screw
22
154301
2
5/16-18 x 5/16” Allen Set Screw
23
100713
1
1/4” x 1/4” x 7/8” Key
24
100189
1
5L650 “V” Belt (to idler assembly)
* Some models require a quantity of 4.
Tumbler Bearing Assembly
