450195-3 www.amdry.com 11
Lint Trap Assembly
Illus. No. Part No. Qty. Description
1 881432 1 Lint Trap ONLY
881433 1 Lint Trap Assembly Complete
(includes illus. nos. 1 thru 5)
2 154200 7 5/32” Pop Rivet
3 150300 3 #10 x 1/2” Hex Washer TEK Screw
4 304100 1 Lint Trap Screen Hold Down
5 800500 2 Lint Screen
6 50419 2 #6 x 1/2” Tamperproof Screw
- 150418 1 Tamperproof Screw Hand Driver
7 108120 1 Chain for Drop Lint Door (10-1/2” length)
