LOCATION AND DESCRIPTION OF
OPERATING CONTROLS
In order to use the full capabilities of the 1332A, it is highly
recomended that the user become familiar with the
controls associated with this instrument. (See Figure 1)
Figure 1. Location of operating controls.
1-Power ON/OFF switch. 7-Current Fine Control Clockwise
rotation increases variable output
current in CC mode.
2-Supply LED Display. 8-CV LED
Display Voltage 0 to 32VDC Constant Voltage mode Indication
3-Supply LED Display. 9-CC LED
Displays current 0 to 5AMP. Constant Current Mode Indication
4-Variable coarse voltage control. 10-Output terminals
Clockwise rotation increases Red terminal is output (+)ve.
variable o/p voltage in CV mode. Black terminal is output (-)ve.
5-Variable fine voltage control. 11-Ground terminal.
Clockwise rotation increases
variable output voltage in CV mode.
6-Current coarse Control.
Clockwise rotation increases variable
output current in CC mode.
4
PCB Components ZSDT-CT/05 PCB
=======================================================================
Ref Designator Value
========================================================================
R37 2K, MFR, 1/4W, 5%
R38 1K, MFR, 1/4W, 5%
R39 1K, MFR, 1/4W, 5%
R40 4.7K, MFR, 1/4W, 5%
R41 330K, MFR, 1/4W, 5%
R42 100E, MFR, 1/4W, 5% (I CAL)
R43* 3.9K, MFR, 1/4W, 5% (I CAL)
R44 1K, MFR, 1/4W, 5%
R45 1K, MFR, 1/4W, 5%
R46* 10K, MFR, 1/4W, 5% (V CAL)
R47* 100E, MFR, 1/4W, 5% (V CAL)
R48 2K, MFR, 1/4W, 5%
R49 Shorting Link
R50 Shorting Link
R51 10E, MFR, 1/4W, 5%
R59 10E, MOR, 2W
PRESETS
PR101
5K, PRE, LIN, (V)(DEV. DROP)
PR102 500E, PRE, LIN, (V)(V CAL)
PR103 500E, PRE, LIN, (V)(I CAL)
CAPACITORS
C1
0.1µF/100V, MP
C2 0.1µF/250VAC MKP
C3 15,000µF/50V ELE
C4 0.1µF/50V, MP 10%
C5 33µF/50V, ELE
C6 100µF/50V, ELE
C7 100µF/50V, ELE
C8 1µF/50V, ELE
C9 4.7µF/50V, ELE
C10 10µF/50V, ELE
C11 100µF/50V, ELE
C12 47µF/50V, ELE
C13 1kpF/50V, CD
C14 1kpF/50V,.CD
C15 0.1µF/50V, CD
C16 10µF/50V, ELE
C17 10µF/50V, ELE
C18 0.1µF/50V, CD
C19 220µF/50V, ELE
