Global Specialties 1332A User Manual
Page 5
STABILITY
Total drift within 8 hours,
: ±0.1% +2.5mV in constant
voltage mode.
after warm up under
: ±0.5% +2mA in constant
current mode.
constant line,load & temp.
PANEL METERS
:
Digital panel meters
(marked V for voltmeter
and A for ammeter) are
provided with an accuracy
of ± 3 counts.
MODE INDICATION
:
Respective LED lights up
when the unit is working
in CV or CC mode.
OUTPUT CONTROLS
: Single turn coarse and fine
voltage and current
controls are provided on
the front panel
OPERATING TEMP.
: 0-40°C.
INPUT VOLTAGE
: 115V / 230V AC, ± 10%,
47 - 63Hz single phase
DIMENSIONS ( W x D x H )
: 230mm x255mm x133mm
WEIGHT
:
9.0Kg. nett. Approx.
3
PCB Components
ZSDT-CT/05 PCB
=======================================================================
Ref Designator
Value
========================================================================
C20
220µF/50V, ELE
C21
47µF/50V, ELE
C22
10µF/50V, ELE
C23
0.1µF/50V, CD
C24
10µF/50V, ELE
C25
10µF/50V, ELE
C26
0.1µF/50V, CD
C27
470µF/50V, ELE
C29
1000µF/35V,ELE
DIODES
CR1
Not Used
CR2
1N4007, 1KV/1A
CR3
1N4007, 1KV/1A
CR4
1N4007, 1KV/1A
CR5
1N4007, 1KV/1A
CR6
1N4007, 1KV/1A
CR7
1N4007, 1KV/1A
CR8
1N4007, 1KV/1A
CR9
1N4007, 1KV/1A
C10
1N4007, 1KV/1A
CR11
1N4007, 1KV/1A
CR12
1N4007,1KV/1A.
CR13
1N4007,1KV/1A.
CR14
1N4007,1KV/1A
CR15
1N4007,1KV/1A
CR16
1N4007, 1KV/1A
CR17
1N4007, 1KV/1A
CR18
1N4007, 1KV/1A
CR19
1N4007, 1KV/1A
CR20
1N4007, 1KV/1A
CR21
1N4007, 1KV/1A
CR22
1N4007, 1KV/1A
CR23
1N4007, 1KV/1A
CR24
1N4007, 1KV/1A
CR25
1N4148, 100V/10mA
CR26
1N4148, 100V/10mA
CR27
1N4148, 100V/10mA
CR28
1N4148, 100V/10mA
CR29
1N4007, 1KV/1A
CR30
1N4007, 1KV/1A
