TABLE OF CONTENTS
GENERAL INFORMATION............................ Page 1
SPECIFICATIONS......................................... Page 2
LOCATION AND DESCRIPTION OF
OPERATING CONTROLS.............................. Page 4
INSTALLATION.............................................. Page 5
OPERATING INSTRUCTIONS....................... Page 6
POWER SUPPLY OPERATION .................... Page 8
SAFETY INSTRUCTION ............................... Page 9
OPERATING PRECAUTIONS........................ Page 10
CASE DISASSEMBLY AND ASSEMBLY....... Page 11
MAINTENANCE AND RECALIBRATION........ Page 11
SERVICE AND WARRANTY INFORMATION. Page 12
PART LIST.................................................... Page 13
SCHEMATIC AND BOARD LAYOUT.............. Page 20
LIST OF ILLUSTRATIONS
FIGURE 1. Location of operating controls...... Page 4
PCB Components Z-TR/01 PCB REV - 01
=======================================================================
Ref Designator
Value
=======================================================================
RESISTORS
R1
1K,2W,5%,MOR
R2 0.1E,2.5W,5%,WW
R129* 33K,0.25W,5%,MFR
CAPACITORS
C1
0.1uF,50V,CD
C2 100uF,50V,EL
C3 10uF,50V,EL
DIODE
CR1
1N5402 X 2
PCB Components CHASSIS & FRONT PANELS
=======================================================================
Ref Designator
Value
=======================================================================
CHASSIS
VARISTOR FOR 115V - 201K
FOR 230V - DNR 20D 361
FILTER YUNPEN EMI 6A/125V/250V
MAINS TRANSFORMER 650VA
INPUT FUSE
FOR 115V - 5Amp TYPE T
FOR 230V - 2.5Amp TYPE T
FRONT PANEL
WW POT 1KE 1W X 2
WW POT 10KE 1W
WW POT 50E 1W
LED GREEN 3mm
LED RED 3mm
ON/OFF SWITCH DPST CHILLY 3022 6A /125V/250V
19
