SECTION - 1
INTRODUCTION
POWER SUPPLY : MODEL1310
The 1310 Power Supply is a versatile triple-output unit which can
be used in both digital and analog circuit applications. It consists
of three independent power supplies: a foxed 5 volt supply rated at
1.0 amps maximum, and two variable 1.3 to 20 volt supplies each
rated at 250 milliamps maximum. The three digit display allows the
voltage of the variable supplies to be quickly and accurately set, and
current flow can be monitored with 1 milliamp resolution.
All three supplies are completely isolated from each other, and from
earth ground. A circuit or piece of equipment connected to any one
of the supplies may be floated to DC level different from the other
two supplies. In addition, any two - or all three - supplies may be
connected to the chassis and earth ground is provided. And, of
course, each supply is protected against short circuit and thermal
overloads.
The 1310 is an excellent general purpose power supply for
engineering lab applications, bread-boarding, and prototyping.
The triple-output voltages make it ideal for working with all
disciplines, from microcomputer components to op-amps. Priced
economically, the 1310 is the perfect choice for production lines,
service shops, hobbyists, and whenever a compact, reliable DC
power supply is needed.
1
20
PCB Components
1310-PS-MAIN PCB
=======================================================================
Ref Designator
Value
=======================================================================
CAPACITORS
C1
22µF, 50V, ELE
C2
22µF, 50V, ELE
C3
1000µF, 35V, ELE
C4
0.1µF, 100V, MP
C5
22µF, 16V, ELE
C6
0.1µF, 100V, MP
C7
22µF, 16V, ELE
C8
0.1µF, 100V, MP
C9
4700µF, 16V, ELE
C10
0.1µF, 100V, MP
C11
22µF, 16V, ELE
C12
22µF, 16V, ELE
C13
0.1µF, 100V, MP
C14
2200µF, 35V, ELE
C15
0.1µF, 100V, MP
C16
22µF, 16V, ELE
C17
22µF, 50V, ELE
C18
0.1µF, 100V, MP
C19
2200µF, 35V, ELE
C20
0.1µF, 100V, MP
C21
0.1µF, 100V, MP
C22
22µF, 50V, ELE
C23
0.1µF, 100V, MP
C24
0.22µF, 100V, MP
C25
0.47µF, 100V, MP
C26
0.1µF, 100V, MP
C27
0.1µF, 100V, MP
C28
100pF, 500V, CD
C29
0.1µF, 100V, MP
C30
0.022µF, 400V, VDC, MP AX
TRANSISTORS
Q1
2N3906
Q2
2N3904
Q3
2N3904
ICs
U1
LM317
U2
LM354
U3
LM317
U4
78S05
U5
7107
