c)

Turn the voltage and current controls fully counter
clockwise.

d)

Connect a DC ammeter or a shunt-digital voltmeter (DVM)
combination across the output terminals using appro-
priately-gauged wire and hardware. The recommended
current ratings for the ammeter or the shunt and the wire
must be atleast 5A. The ammeter or shunt-DVM
combination must be rated better than 0.5% accuracy.

e)

Turn the AC power switch ON. The front panel digital
meters will light up and voltmeter and ammeter displays
will read zero.

f)

Turn the Voltage control knob clockwise.

h)

Turn the Current control slowly clockwise.

g)

Compare the ammeter reading with the front panel
ammeter reading. Calculate the output current I using the
formula I=V/R where V is the DVM reading and R is the
resistance of the external shunt.

The control range will be from 0 to 5A. The red current
mode LED will be illuminated to indicate CC mode of
operation.

4.3

LOAD CONNECTIONS :
Each load should be connected to the power supply
output terminals using separate pairs of connecting wires.
This will minimize mutual coupling effects between
loads and will retain full advantage of the low output
impedance of the power supply. Each pair of connecting
wires should

4.4

REVERSE VOLTAGE LOADING :
A diode is connected across the output terminals. Under
normal operation, the diode is reverse biased (anode
connected to the negative terminal). If a reverse voltage
is applied to the output terminals(positive voltage applied

5

PCB Components

ZSDT-CT/05 PCB

=======================================================================

Ref Designator

Value

========================================================================

PRESETS

PR101

5K, PRE, LIN, (V)(DEV. DROP)

PR102

500E, PRE, LIN, (V)(V CAL)

PR103

500E, PRE, LIN, (V)(I CAL)

CAPACITORS

C1

0.1µF/100V, MP

C2

0.1µF/250VAC MKP

C3

15,000µF/50V ELE

C4

0.1µF/50V, MP 10%

C5

33µF/50V, ELE

C6

100µF/50V, ELE

C7

100µF/50V, ELE

C8

1µF/50V, ELE

C9

4.7µF/50V, ELE

C10

10µF/50V, ELE

C11

100µF/50V, ELE

C12

47µF/50V, ELE

C13

1kpF/50V, CD

C14

1kpF/50V,.CD

C15

0.1µF/50V, CD

C16

10µF/50V, ELE

C17

10µF/50V, ELE

C18

0.1µF/50V, CD

C19

220µF/50V, ELE

C20

220µF/50V, ELE

C21

47µF/50V, ELE

C22

10µF/50V, ELE

C23

0.1µF/50V, CD
