Global Specialties 1305 - Manual - Manual (Page 2)

TABLE OF CONTENTS
SECTION PARTICULARS PAGE NO.
1 GENERAL INFORMATION 1
2 SPECIFICATIONS 2
3 INSTALLATION 3
4 OPERATING INSTRUCTIONS 4
5 PART LIST 8
6 CIRCUIT DIAGRAM 16
PCB Components 2 X Z-DPM/01 PCB REV - 01
=======================================================================
Ref Designator
Value
=======================================================================
MISCILLANEOUS
J1
2.54PITCH,5PIN M
J2 2.54PITCH,3PIN M
J3 2.54PITCH,4PIN M
PCB Components 2 X Z-TR/01 PCB REV - 01
=======================================================================
Ref Designator
Value
=======================================================================
RESISTORS
R1
1K,2W,5%,MOR
R2 0.1E,2.5W,5%,WW
R129* 33K,0.25W,5%,MFR
CAPACITORS
C1
0.1µF/50V, CD
C2 10µF/50V, ELE
C3 2.2µF/50V, ELE
DIODE
CR1
1N5402 X 2
FRONT PANEL & CHASSIS
=======================================================================
Ref Designator Value
=======================================================================
V' COARSE CONTROL 10K/1W W/W POT X 2
V' FINE CONTROL 1K/1W W/W POT X 2
I' COARSE CONTROL 1K/1W W/W POT X 2
I' FINE CONTROL 50E/1/W W/W POT X 2
INPUT FILTER EMI 10AMP/125V
ON / OFF SWITCH CHILLI 3022
INPUT FUSE FOR 230V -- 4AMP/TYPE 'T'
FOR 115V -- 8AMP/TYPE 'T'
15
