PCB Components
5051A-KBD-0306
=======================================================================
Ref Designator
Value
========================================================================
SWITCH
S1 TO S6
ITTD 6 KEY BOAR
DBLACK HEIGHT 6mm
CONNECTORS
J1
DUAL IN ROW UNLOC MALE
STRAIGHT BURGE STRIP, 16 PIN
PCB Components LCD ASSY-16X2 HY-1602F-205 YELLOW
=======================================================================
Ref Designator
Value
========================================================================
CONNECTORS
J1
16 PIN ST BREG STRIP BLACK
MECHANICALS
=======================================================================
Ref Designator
========================================================================
20A MAINS CORD
FUSE 20A
FUSE HOLDER 20A
115V SOCKETS AMERICAN 16A x 2
ON / OFF SWITCH 16A x 2
