PCB Components 5051A-MAIN-0306 IRD 551
=======================================================================
Ref Designator Value
========================================================================
CAPACITORS
C16 18nF SMD 0805
C17 100nF / 50V 10% 0805SM
C18 10µF / 16V 2010MIL SMD ELE RAD
C19 33pF SMD CHIP 0805
C20 33pF SMD CHIP 0805
C21 100nF / 50V 10% 0805SM
C22 100nF / 50V 10% 0805SM
C27 3300µF / 35V 20% ELE RAD
C28 330µF / 25V ELE RAD
C29 10µF / 16V 2010MIL SMD ELE RAD
C30 100nF / 50V 10% 0805SM
C31 10µF / 16V 2010MIL SMD ELE RAD
C32 100nF / 50V 10% 0805SM
C33 10µF / 16V 2010MIL SMD ELE RAD
C34 100nF / 50V 10% 0805SM
C35 10µF / 16V 2010MIL SMD ELE RAD
C36 100nF / 50V 10% 0805SM
C37 1µF SMD CHIP 0805
C38 100nF / 50V 10% 0805SM
C39 100nF / 50V 10% 0805SM
C40 100nF / 50V 10% 0805SM
C41 100nF / 50V 10% 0805SM
C42 100nF / 50V 10% 0805SM
C43 ELE RAD 10µF, 16V
C44 100nf 50V CFI CHIP
CRYSTAL
X1 12MHz
X2 4.194304MHz
DIODE
D1 TO D4 1N4003 SMD MELF1
D5 RLS4148 T E11 SMD
ICs
U1 CS5460A 1PH POWER ENERGY 24 PIN TYPE SSOP
U2 89S52 UC 40 PIN 8 BIT FLASH 8KB ( DIP40 )
U3 74HC4053 16 PIN 2 CHANNEL ANALOG TYPE SO-16
U4 MNC 93C46N PI27 ATMEL MAKE ONLY
U5 LMV331 SMD 5 PIN LOW VOLTAGE COMPARATOR SOT23-5
U7 TL431-CP ADJ PRECISION REG SHUNT ( SOT23M1 )
U8 74HC14 SMD ( SO-14 ) HEX INVERTING SCHMIT TRIGGER
U9 IC UA7805UC REG / LM7805CT +5V
U10 UA7905UC REG -5V FIX
U11, U12 OP07 8 PIN SMD OP AMP ( SO8 ) ULTRA LOW-OFFSET
CONNECTORS
J1 4 PIN 2.54mm MALE
J2 DUAL IN ROW UNLOC MALE STRAIGH BURGE STRIP, 16 PIN
J3 3 PIN 2.54mm MALE
J4 4 PIN 2.54mm MALE
J5 DUAL IN ROW UNLOC MALE STRAIGTH BURGE STRIP, 10 PIN
JP1, JP3, JP5 3 PIN JUMPER MALE BREG STRIP BLK
JP7 2 PIN 2.54mm JUMPER LINK SIL MJ-02
SWITCH
SW1 TACT SWITCH TINY
