1-10
Section 1 Introduction Installation and Operation Manual
X-VA-FC-eng
Part Number: 541B045AAG
March, 2012
Flow Controllers for Gas and Liquid Service
Table 1-4 Model Code
APPLICATION
FCA87
Low flow gases and liquids with variable downstream pressure
FCA88
Gases and liquids with variable upstream pressure
FCA89
Gases and liquids with variable downstream pressure
TYPE OF USE
00
General use, standard operating pressure, integral connection to Models 1350 & 1355
02
General use, standard operating pressure, integral NPT connections
05
General use, high operating pressure, integral NPT connections
12
High flow rates, standard operating pressure, integral NPT connections
15
High flow rates, high operating pressure, integral NPT connections
30 Very high flow rates, standard operating pressure, integral NPT connections
40
Precise control, standard operating pressure, integral connection to Models 1350 & 1355
42
Precise control, standard operating pressure, integral NPT connections
45
Precise control, high operating pressure, integral NPT connections
44 Very precise control, low operating pressure, adapters required
DIAPHRAGM MATERIAL
1
Viton
2
Teflon
3
Buna
O-RING MATERIAL
A
Viton
B
Buna
C
Kalrez SS body only
D
Kalrez/Teflon SS body omly
E
EPR SS body only
Y
Not Applicable
PROCESS CONNECTION SIZE & TYPE
1
1/4" F-NPT
2 1/8" F-NPT
3
1/8" Tube Compression
4
1/4" Tube Compression
5
1/4" I.D. Hose
6
3/4" F-NPT
7
Integral 5/16-24 UNF Thd
BODY MATERIAL
A
Brass
B
316 Stainless Steel
C
Aluminum FC 8744 only
