XP-SKX PARTS LIST
Pump Model XP-SKX15CSS XP-SKX22CSS XP-SKX37CSS XP-SKX55CSS XP-SKX75CSS XP-SKX110CSS XP-SKX150CSS
Pos. No. Part Description Item # Item # Item # Item # Item # Item # Item #
01-2 Stand Only 201995 201989 201994 201999 201999 202001 202001
02 Suction Cover - - - 202881 202881 202040 202040
03 Impeller Nut 202894 202894 202894 202897 202897 202897 202897
3 Upper Ball Bearing (See EIM Manual) 200959 200959 200959 200968 200968 200968 200962
04 Impeller Washer 202907 202907 202907 202917 202917 202917 202917
05 Impeller 202962 202965 202968 202137 202139 202946 202948
06 Impeller Key 202140 202140 202140 202146 202146 202146 202987
6 Stator 208V (See EIM Manual) 200969 200971 200973 - - - -
6 Stator 230V (See EIM Manual) 200969 200971 200973 200975 200977 200979 200981
6 Stator 460V (See EIM Manual) 200969 200971 200973 200975 200977 200979 200981
6 Stator 575V (See EIM Manual) 200970 200972 200974 200976 200978 200980 200982
07 Pump Housing 202172 202177 202181 202190 202190 202194 202194
7 & 8 Rotor/Shaft Assy. (See EIM Manual) 200983 200984 200985 200986 200987 200988 200989
12L Mating Plate / Oil Chamber Cover
09 Lip Seal FKM 202232 202235 202235 202242 202242 202242 202242
9 Lower Ball Bearing (See EIM Manual) 200961 200961 200961 200494 200949 200495 200496
10 Mechanical Seal - FKM (See EIM Manual) 200338 200338 200338 200339 200339 200339 200340
38 Discharge Nipple 3" 202535 202535 202535 - - - -
38E Discharge Elbow 202559 202559 202559 202573 202573 202574 202574
38E-1 Gasket, Discharge Elbow FKM 203327 203327 203327 203211 203211 202664 202664
38F Discharge Flange 3" 202546 202546 202546 - - - -
38F Discharge Flange 4" - - - 202576 202576 - -
38F Discharge Flange 6" - - - - - 202549 202549
38F-1 Gasket, Discharge Flange FKM 202724 202724 202724 202662 202662 202664 202664
50-01-2 Bolt for Strainer/Stand 203228 203228 203228 203236 203236 203279 203279
50-02 Bolt for Suction Cover - - - 203236 203236 203279 203279
50-07 Bolt for Mating Plate to Volute 203229 203229 203229 203236 203236 - -
50-11V Air Release Valve - - - 202707 202707 202707 202707
50-38E Bolt for Discharge Elbow 203271 203271 203271 203276 203276 203278 203278
50-38F Bolt for Discharge Flange 203294 203294 203294 203277 203277 203278 203278
49 Bell Mouth (See EIM Manual) Pwr Cable Assy. Pwr Cable Assy.Pwr Cable Assy.Pwr Cable Assy.Pwr Cable Assy. Pwr Cable Assy. Pwr Cable Assy.
49-SN Stud & Nut - Bell Mouth (See EIM Manual) Pwr Cable Assy. Pwr Cable Assy.Pwr Cable Assy.Pwr Cable Assy.Pwr Cable Assy. Pwr Cable Assy. Pwr Cable Assy.
50 Cable Bushing (See EIM Manual) Pwr Cable Assy. Pwr Cable Assy.Pwr Cable Assy.Pwr Cable Assy.Pwr Cable Assy. Pwr Cable Assy. Pwr Cable Assy.
54 Cable (See EIM Manual) Pwr Cable Assy. Pwr Cable Assy.Pwr Cable Assy.Pwr Cable Assy.Pwr Cable Assy. Pwr Cable Assy. Pwr Cable Assy.
55 Cable clamp (See EIM Manual) Pwr Cable Assy. Pwr Cable Assy.Pwr Cable Assy.Pwr Cable Assy.Pwr Cable Assy. Pwr Cable Assy. Pwr Cable Assy.
55-B Bolt (See EIM Manual) Pwr Cable Assy. Pwr Cable Assy.Pwr Cable Assy.Pwr Cable Assy.Pwr Cable Assy. Pwr Cable Assy. Pwr Cable Assy.
200998 200998 200999 200999 - -
200998 200998 200999 200999 201000 201000 -
200998 200998 200998 200998 200998 200999 201001
200998 200998 200998 200998 200998 200999 201001
49 Bell Mouth (See EIM Manual) Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit
49-SN Stud & Nut (See EIM Manual) Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit
50 Cable Bushing (See EIM Manual) Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit
55-B Bolt (See EIM Manual) Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit
55 Cable clamp (See EIM Manual) Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit Pwr Cable Kit
200233 200233 200291 200291 - - -
200233 200233 200291 200291 200328 200328 -
200233 200233 200233 200233 200233 200291 200330
200233 200233 200233 200233 200233 200291 200330
2-R O-Ring (See EIM Manual) O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit
5-R1 O-Ring (See EIM Manual) O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit
5-R2 O-Ring (See EIM Manual) O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit
12U-R O-Ring (See EIM Manual) O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit
28-P O-Ring (See EIM Manual) O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit O-Ring Kit
200341 200341 200341 200342 200342 204168 200343
Pwr Cable Kit 230V
Pwr Cable Kit 460V
Pwr Cable Kit 575V
O-Ring Kit-FKM
See the EIM Electric Co., LTD I O & M Manual
Pwr Cable Assy.208V
Pwr Cable Assy.230V
Pwr Cable Assy.460V
Pwr Cable Assy.575V
Pwr Cable Kit 208V
