KZN R PARTS LIST
Pump Model KZN37R KZN55R KZN55CHR KZN75R KZN110R KZN110HR KZN150R KZN150LR KZN220R KZN220LR
Pos. No. Part Description Item # Item # Item # Item # Item # Item # Item # Item # Item # Item #
01N-01 Stand w/ Strainer Plate 201982 201982 201983 201982 201981 201981 201981 201981 201984 201984
02 Wear Plate 202018 202018 202019 202023 202016 202016 202016 202867 202030 202030
02W Suction Cover 202869 202869 202870 202873 202874 202874 202874 202875 202876 202877
04 Lock Washer 202917 202917 202917 202917 202918 202918 202918 202918 202919 202919
05 Impeller 202976 202977 202979 202980 202981 202982 202972 202973 202974 202975
05W Agitator 202983 202983 202983 202983 202984 202984 202984 202984 202985 202985
06 Impeller Key 202146 202146 202146 202146 202147 202147 202147 202147 202986 202986
07 Pump Housing 202193 202193 202192 202193 202204 202204 202204 202204 203035 203035
07-3 Pump Housing Sleeve 202182 202182 202182 202182 202183 202183 202183 202183 202184 202184
08 Oil Chamber Cover 202225 202225 202225 202225 202227 202227 202227 202227 203049 203049
08 -1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
09 Lip Seal Buna N 202248 202248 202248 202248 202251 202251 202251 202251 202244 202244
10 Shaft Sleeve 203071 203071 203071 203071 203072 203072 203072 203072 203073 203073
12 Upper Lip Seal Buna N - - - - 202252 202252 202252 202252 203063 203063
13 Mech. Seals - Set FKM** 200419 200419 200419 200419 200433 200433 200433 200433 200433 200433
13-2 Mech. Seal Retainer - - - - 202272 202272 202272 202272 202272 202272
14 Lower Ball Bearing ( * =Qty 2 Needed) 200963 200963 200963 200963 200964 200964 200964 200964 200965* 200965*
14-2 Lower Bearing Retainer 202276 202276 202276 202276 202277 202277 202277 202277 202278 202278
14-3 Retaining Locknut & Ring - - - - - - - - 202275 202275
16 Motor Housing. 202295 202295 202295 203081 203082 203082 203082 203082 203083 203083
17 Rotor w/ Shaft, 3 phase 202349 202350 202350 202351 202352 202352 202353 202353 202354 202354
18 Stator 230V/460V 3 phase 200681 200681 200683 200685 200687 200687 - - - -
18 Stator 460V 3 phase - - - - - - 200689 200689 200691 200691
18 Stator 575V, 3 phase 200695 200697 200697 200699 200693 200693 200701 200701 200703 200703
20 Upper Ball Bearing 200968 200968 200968 200968 200968 200968 200968 200968 200962 200962
20-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
20-2 Spring Washer 202361 202361 202361 202361 202362 202362 202362 202362 202363 202363
21A Lower Bearing Housing 202377 202377 202377 202377 - - - - - -
21A Oil Chamber - - - - 202371 202371 202371 202371 202372 202372
21A-1 O-Ring (Kit Only) - - - - Kit Kit Kit Kit Kit Kit
21A-1 O-Ring (Kit Only) Kit Kit Kit Kit - - - - - -
22 Cover Plate Upper - - - - - - - - 202381 202381
23 Overload 230V, 3PH 202392 202394 202394 202396 202397 202397 - - - -
23 Overload 460V, 3PH 202391 202393 202393 202394 202398 202398 202397 202397 202400 202400
23 Overload 575V, 3 PH 202389 202391 202391 202393 202394 202394 202398 202398 202397 202397
26 Pump Top Cover 203136 203136 203136 203136 203137 203137 203137 203137 203138 203138
26-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
27 Bolt - Suction Cover 2733 2732 2732 2732 2734 2734 2734 2734 2735 2735
27 Power Cord Set (5 lead) 203452 203455 203455 203455 203456 203456 203456 203456 203457 203457
27-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
27-2 Power Cord Housing 202490 202490 202490 202490 202493 202493 202493 202493 203160 203160
