DS-4/DS-10 SPECIFICATIONS
Desk Station 4/10 SPECIFICATIONS
Frequency Response (electronics):
+0,-1dB, 100Hz to 20kHz
A/D Converters:
24-bit (48kHz sampling)
Effective Input Headroom:
30dB
Connection:
RJ45 with shielded Ethernet/PoE cable
(CAT5, CAT5e, CAT6 or CAT7)
Gain:
Adjustable in 1dB steps
over a 30dB range
Power:
802.3af (PoE) Class 2
System Headroom:
18dB
Overall Dimensions
(excl. microphone):
Height:
Width:
Depth:
2.1 inches (54mm)
9.5 inches (241mm)
7.4 inches (187mm)
Maximum Input:
125dB SPL
Mic Gooseneck Length:
12.5 inches (317.5mm)
THD + N (100Hz to 8kHz):
<0.05%
Weight:
Approx. 3.0 8lbs. (1.4kg)
Mic Type:
Electret condenser
Ambient Operating
Temperature Range:
32-113 degrees F (0-45 degrees C)
Mic Pattern:
Mic Frequency Response:
Cardioid dynamic microphone
with dual transducer (monitored)
100Hz-10kHz
Compliance:
FCC Part 15, class B
CE marked
RoHS Directive
UL 60065 Listed, E215636
C-UL Listed, E215636
C-Tick, N24138 (Australia
Desk Station 4/10 BLOCK DIAGRAM
