14
Kit Number Description
KIT320RK Overhaul Kit
KIT320RG Rotor & Vane Kit
KIT320SL Seal Kit
KIT320BV By-Pass Service Kit
Parts
Rotor, rotor cover, vanes, O-ring seal, shaft
seal kit, bypass valve, inlet seal & screen,
rotor key, attaching hardware
Rotor cover, rotor, vanes, rotor key, O-ring
seal, attaching hardware
O-ring, shaft seals, retainer clip
Inlet gasket, screen, bypass valve, valve
spring, valve retainer
KIT120NB Nozzle Boot Kit Nozzle boot, attaching hardware
KIT320SK External Seal Kit
O-ring seal, inlet gasket, electrical cover
seals
KIT320BG Inlet Flange Kit
Inlet flange (bung), attaching hardware, inlet
seal, screen
KIT320SW Switch / Breaker Kit
Breaker / switch assembly, switch mounting
bracket, attaching hardware, cover gasket
KIT320MK Motor Kit Complete motor assembly
Kits and Parts
