10
C 230 ECO
20/02/09 - 300015144-001-C
4.2.2
Control panel K3
Make all settings on the master boiler fitted with a DIEMATIC-m3
control panel
Press the
*
key.
Access to the parameters of the slave boilers (Panel K3) in a cascade
• Boiler temperature display on the master boiler
Number of the boiler for which the parameters are displayed
`
Press the
*
key
The number of the boiler displayed corresponds to the setting
on the coding wheel.
• Boiler temperature display on the slave boiler
Number of the boiler for which the parameters are displayed
All parameters and measurements on the slave boilers (Control
Panel K3) can be accessed with the control panel keys DIEMATIC-
m3.
Key
*
is used to transmit all information from the slave boilers
(Control Panel K3) to the master boiler (DIEMATIC-m3 Control
Panel).
The parameters on the slave boilers can be read on the control panel
display DIEMATIC-m3.
If no keys are pressed for 10 seconds, the control panel display
returns to the master boiler (Number 1).
Adjustme
nt (Code
wheel)
Number of the boiler for which the parameters are
displayed
0
1
Master boiler (Control panel
DIEMATIC-m3)
1
2
”Follower - 1” boiler
(Control panel K3)
2
3
”Follower - 2” boiler
(Control panel K3)
etc.
0
2
4
6
8
10
12
14
16
18
20
22
24
A
BOILER TEMP.
0
2
4
6
8
10
12
14
16
18
20
22
24
A
BOILER TEMP.
