Rev. 4/00 -1.6- D601
The D601 employs modular construction and
provides electrical safety for the operator. The
display face contains voltages no greater than 9 Vdc
and any exposed metal work is electrically connected
to Earth Ground. The display face swings open to
allow access to user connections.
The serial number and complete model number of
your D601 is located on the inside of the transmitter
front cover. Should technical assistance be required,
please provide the Dynasoncs’ Customer Service
Department with this information. Email:
A part number breakdown of the transducer and
transmitter portions of the flowmeter are described
below.
PART 1 - GENERAL
Transmitter
Transducer
Serial Number
