Page 8

CH1

CH2

CH4

SPLIT(2-WAY)

SPLIT(3-WAY)

SPLIT(4-WAY)

Figure 3: Source Select Sequence
(CH3 "Skip" )

Primary Function Input Source Select

-Pressing the SELECT button to sequence the source input modes
as indicated in Figure 2.
-Source input modes that are skipped through the menu control
function will be skipped. (Figure 3 shows sequence with
CAM/INPUT 3 skipped.)
-Source ID is indicated by OSD in the top left corner of the screen.
-Source NAME is indicated by OSD in the bottom center of the screen.

Secondary Function Menu Option Selection

-While in Menu mode, the SELECT button is used to select the
highlighted function or option setting.

Third Function Scan Pause / Start

-While in source "SCAN" mode, pressing the select button will stop
the scan and display the current source. "Pause" will be displayed
by OSD.
Press SELECT again to resume source scan.

3. SELECT

SELECT

Figure 2: Source Select Sequence
(All Source Options "On" )
