13
A O M - 7 6 9 4 A O M - 7 6 9 4
PRODUCT SPECIFICATIONS
LCD PANEL SPECIFICATIONS
7" (DIAGONAL) TFT LCD
500 cd/㎡ (typ)
300 (typ)
Top (12 o'clock)
60° (mi n)
±60° (mi n)
Fall : 18 ms (typ)
Backlight Type
10,000 hrs (mi n)
Size/Type
Brightness
Contrast Ratio
View Angles 40° (mi n)
Bottom (6 o'clock)
(@ CR≥10)
Horizontal
Response Time
Rise : 12 ms (typ)
CCFL
Backlight Life
Operation Temperature Range : -20℃ ~ +65℃
Storage Temperature Range : -40℃ ~ +80℃
Max Humidity : 85%
Operation Voltage Range : DC 10V ~ 32V
Current Draw (typical) : Max 30W
Signal system : NTSC or PAL (selectable)
Video Aspect Ratio : 16 : 9
Input Level : 1Vp-p 75Ω Ω
Audio Input Level : Max 0.2 W-150 ㎷ ㎷
Product Weight :
Product Dimensions :
2.2 Ibs / 1Kg
Monitor Only Dimensions:
7.75 W X 5.25 H X 1.25D inches
Flange Dimensions
9.25 W X 6.25 H X 2 D inches
