AW Gateway
QUICK START GUIDE
Windows: : Microsoft® Windows® XP with SP3, Microsoft® Windows® 7 with
SP1, Windows 8, Windows 8.1 or above, 50 MB of available hard-disk space for
installation. LAN connection.
Mac OS: Mac OS X Lion v10.7, Mac OS X Mountain Lion v10.8, Mac OS X
Mavericks v10.9 or above, 50 MB of available hard-disk space for installation.
LAN connection.
AW Gateway acts as a gateway between any single TCP connection device like Di-VentiX II,
Eikos, Pulse as well as the Midra™ switchers and one or more event controllers. With
AW Gateway, you can connect simultaneously up to 5 interfaces (Remote Control Software,
Remote Control Keypad, AMX/Crestron drivers, …) to one single Analog Way switcher.
SYSTEM REQUIREMENTS AND LIMITATIONS
OVERVIEW
QUICK INSTALL AND SETUP
• Installing AW Gateway on Windows
Download the latest version of the AW Gateway installer for Windows (the file name is
SetupAWGateway_.exe). Double-clicking this file will launch the installer that
will install AW Gateway on your system.
• Installing AW Gateway on Mac OS X
Download the latest version of the AW Gateway installer for Mac OS X (the file name is
SetupAWGateway_.pkg). Double-clicking this file will launch the installer that
will install AW Gateway on your system.
• Configuring AW Gateway
Start the AW Gateway application by clicking the corresponding icon. Enter the local
TCP port number on which to listen for incoming connections (default is 10500). When
ready, click Start to start listening for incoming connections. If the server has been
started successfully, the application displays Started – Connections 0/5 .
Enter the IP address of the Analog Way switcher you want to connect as well as the
corresponding TCP port number (default is 10500). Make sure your firewall is opened
for the entered port number. When ready, click Connect to attempt a connection to the
remote host. If the connection is successful, the application displays Connected .
