AmpliVox SS / SW3230 RTA ASSEMBLY INSTRUCTIONS
12
SPEAKERS
• Looking inside of cabinet you will see the backside of
the speaker enclosure. Unwrap speaker wires and
bring them to the front of the amplifier. Plug them into
the speaker jacks marked "L - SPEAKER - R".
• Moving to the front of the cabinet, take Panel (12)
Speaker Grille and align the four fasteners on the
backside of the grille with the four cups on the
panel. Press grille into place.
8/30/12
