Page 38

38
Waterside Economizer Piping Kit
Figure 12 - SA Series Unit with Waterside
Economizer Piping
For single cabinet units connect the three
factory provided piping assemblies. For dual
cabinet units connect both sets of factory
provided piping assemblies.
Connect the piping assembly to the unit.
Connect the actuators to the water valves.
Actuators are factory wired and included
inside the unit.
Installing contractor is responsible for
properly sizing and installing water
system components. Improper fluid
flow due to valves, piping, or
improper pump operation may result
in unacceptable unit operation and
void warranty.
CAUTION
