AAON SA-070 - Manual (Page 13)

SA Series Feature String Nomenclature
GEN S
IZ
E
V
L
T
C
ON
FIG
A1 A2 A3 A4 B1 B2 B3 1A 1B 1C 1D 2 3 4 5A 5B 5C 6A 6B 6C 7 8 9 10 11 12 13 14A 14B 15
SA - 035 - 3 - A - E R 0 9 - 0 0 0 : A C 0 0 - 0 0 0 - E B F - A B 0 - 0 0 0 0 0 0 0 - H A - 0
0 0 0 0 0 0 0 B
16 17 18 19 20 21 22 23
13
Feature 5: SUPPLY AIR OPTIONS
5A: SUPPLY AIR BLOWER CONFIGURATION
0 = 2 Blowers + Standard Efficiency Motors
A = 4 Blowers + Standard Efficiency Motors
B = 2 Blowers + Premium Efficiency Motors
C = 4 Blowers + Premium Efficiency Motors
E = 2 Blowers + Premium Efficiency Motors + 2
VFDs
G = 4 Blowers + Premium Efficiency Motors + 4
VFDs
H = 1 Blower + Standard Efficiency Motor
J = 1 Blower + Premium Efficiency Motor
K = 1 Blower + Premium Efficiency Motor + 1 VFD
5B: SUPPLY AIR BLOWER
A = 18.5” Spring Isolated Direct Drive Backward
Curved Plenum
B = 22” Spring Isolated Direct Drive Backward
Curved Plenum
5C: SUPPLY AIR BLOWER MOTOR
C = 1 hp - 1760 rpm
D = 2 hp - 1760 rpm
E = 3 hp - 1760 rpm
F = 5 hp - 1760 rpm
G = 7.5 hp - 1760 rpm
H = 10 hp - 1760 rpm
N = 1 hp - 1170 rpm
P = 2 hp - 1170 rpm
Q = 3 hp - 1170 rpm
R = 5 hp - 1170 rpm
S = 7.5 hp - 1170 rpm
Feature 6: FILTERS
6A: PRE FILTER TYPE
0 = No Pre Filter
A = 2” Pleated - 30% Eff. - MERV 8
6B: UNIT FILTER TYPE
0 = 2” Pleated - 30% Eff. - MERV 8
A = 4” Pleated - 30% Eff. - MERV 8
B = 4” Pleated - 65% Eff. - MERV 11
C = 4” Pleated - 85% Eff. - MERV 13
D = 4” Pleated - 95% Eff. - MERV 14
6C: FILTER OPTIONS
0 = Standard
A = Clogged Filter Switch
B = Magnehelic Gauge
C = Options A + B
Feature 7: REFRIGERATION
CONTROL
0 = Standard
A = 5 Min. Time Delay Relay - Comp. Off
B = 20 Sec. Time Delay Relay - Comp. Staging
C = Freeze Stats - Each Circuit
D = Options A + B
E = Options A + C
F = Options B + C
G = Options A + B + C
Feature 8: REFRIGERATION OPTIONS
0 = Standard
D = Modulating Hot Gas Reheat
