Program A and Program B
This series of menus lets you drill down to all the possible options for either Program.
Audio 1 Input Sets audio for the currently selected source. If you plan on switching sources in your
application, select each video input, then select the associated audio. The audio will then
automatically follow the selected video input.
None | SDI G1 | SDI G2 | SDI G3 | SDI G4 | Optical | Coax | Analog 1|Analog 2
Audio 1 Format Selects audio format for stereo PCM or analog audio. Incoming AC3 audio encoding will be
passed through.
AC3 | MP12
Audio 1 Lang
Displays metatext for audio channel language.
English | Spanish | Portuguese |French|German
Audio 2 Input Sets the source for the second audio track for the selected video input.
None | SDI G1 | SDI G2 | SDI G3 | SDI G4 | Optical | Coax | Analog 1|Analog 2
Audio 2 Format Selects audio format for stereo PCM or analog audio. Incoming AC3 audio encoding will be
passed through.
AC3 | MP12
Audio 2 Lang
Displays metatext for audio channel language.
English | Spanish | Portuguese |French|German
Video Input Select the video input
SDI | YPbPr | Video 1| Video 2
Resolution When the scaling option is active, you can specify the output resolution. When it’s not, the
output will be set by the input.
1080i | 720p | 480p | 480i
Bitrate (Mbps)
Bitrate is adjustable in half steps from 10-25. Default rate will be 18 Mbps, and settings will
be limited to 18 when 2-channel mode is enabled.
Chan Major ID Major virtual channel ID for program. Default is 000, will automatically insert the physical
channel number as the Major ID.
Chan Minor ID
Minor virtual channel ID. Default is 1, if set to 000, channel ID will only use the Major
channel ID
Chan Name Enters channel short name, up to 7 characters. QMOD A or QMOD B is default text.
Press right or left arrow to start editing, use Up and Down arrows to select character.
No Vid Color Sets background color displayed when no video is present
Orange | Purple (default) | Green
Major ID Major virtual channel ID for program. Default is 000, will automatically insert the physical
channel number as the Major ID.
Minor ID Minor virtual channel ID. Default is 1, if set to 000, channel ID will only use the Major
channel ID
Name
Enters channel short name, up to 7 characters. “QMOD” is default text.
Press right or left arrow to start editing, use Up and Down arrows to select character.
Sync Trig Level May help how fine details are displayed
1-4
Horiz Freq Shows horizontal frequency of source
Vertical Freq Shows vertical frequency of source
Lines Shows number of lines in source video
